Product Features:
Liquid Cooling Design
Designed for altitudes up to 4000m with optional C5 corrosion protection.
Wide Temperature Tolerance
Operates reliably from -30°C to +50°C, with power derating above 45°C.
High Energy Density
Equipped with 314Ah high-quality cells, delivering 340kWh/m² in a standard 20-foot container.
Remote Monitoring & Communication
Supports OTA updates and complies with IEC104 / IEC61850 communication protocols.
Technical Specifications:
| Product Model | AI-Ocean-5016D |
| Battery Type | LFP 3.2V,314Ah 416S12P |
| Dimensions (W × D × H) | 6058×2438×2896mm |
| Weight | ~45t |
| System Capacity | 5016kWh |
| Protection Level | IP54 C4/C5 |
| Cooling Method | Liquid Cooling |
| Operating Conditions | -30~50℃ |
| Fire Protection | Aerosol+ Water Fire Protection (optional) |
| Communication | OTA Remote Function，IEC104/ IEC61850 communication protocols |
